Magtek eDynamo BlueTooth

Securely accept magstripe and chip cards using your iPhone, iPad, Android or Windows devices.

Go wireless or connect via USB

Go Bluetooth LE and connect to your favorite iOS, Android or Windows device. The low energy power consumption extends the life of its rechargeable batteries. If wireless is not preferred, then use the Micro-USB cable and connect to a PC or mobile device with a USB host.

Handheld or docked, you choose

Take eDynamo mobile and hold it in your hand. The optional docking station gives merchants the ability to extend the length of the swipe path and mount the device where it makes sense for comfortable card reading.

EMV compliance made simple

A suite of Software Development Kits are available for Apple, Android and Windows operating systems.

Manufacturer: Magtek
Delivery date: 1-2 days
$187.50

Standard Configurations

Description P/N
Black, EMV Chip and swipe reader 21079802
Optional docking station 21079809

General Information


Interfaces Wireless
USB HID
Color Black
Magstripe 3 track, ISO 7810 and ISO 7811/ AAMVA
EMV Chip EMV LEVEL1 CONTACT and EMV LEVEL2 CONTACT
Operating System iOS 7.1 and newer and Android 4.4.2 and newer
USB Windows 7/8/10
Wireless Windows 8.1 on hosts with Wireless hardware
Card Speed 4/6 to 60 ips (10.1 to 152.4 cm/s)
EMV insertions 100k

Security and Certifications


Compliance
MagneSafe Security Triple DES encryption, DUKPT key management, Tokenization, Authentication, Dynamic Data
MagnePrInt Card authentication, counterfeit card detection
Tamper Resistance Tamper resistant and evident
Remote Services Via USB connection
Device Management Unique non-changeable serial number, time-bound session IDs

Electrical


Power Input 5V from USB bus
Current
Normal mode 110 mA maximum

Mechanical


Dimensions Length: 2.48 in (62.9mm)
Width: 0.96 in (38.5mm)
Height: 1.52 in (24.5mm)
Cable Length 6 ft.
Wired Connection Micro-USB B, configured to appear as HID
Wireless Connection Types Wireless configured to appear as a GATT device
Wireless Range Minimum 33 ft. (10 m) in line-of-sight conditions

Environmental


Temperature
Operating 0 °C to 45 °C (-32 °F to 113 °F)
Storage -20 °C to 60 °C (-4 °F to 140 °F)
Humidity
Operating 5% to 90% noncondensing
Storage 5% to 90% noncondensing
Altitude
Operating 0-10,000 ft. (0-3048 m.)
Storage 0-10,000 ft. (0-3048 m.)
